Three-beam and four-column hot press Composite material anti-collision type cushion plate
This hydraulic press is a hydraulic pressure equipment specially designed for the molding of composite material crash cushion plate, which is mainly used to press fiber-reinforced composite materials (such as fiberglass, carbon fiber), metal-plastic composite plate, rubber-metal composite plate and other materials through stamping,Molding or hot pressing process to form crash cushions with energy-absorbing and cushioning functions.Its core features are high pressure control precision, multi-process adaptability and targeted design of composite material characteristics (e.g. avoiding delamination, ensuring inter-layer bonding strength).
- 2000-ton capacity
- Energy saving design
- Low maintenance
- CE certified
Description
315 tons three-beam four-column hydraulic press is a kind of special equipment that generates high pressure through hydraulic system and carries out pressing, stretching, bending and other processes on metal or non-metallic materials.Its core structure adopts three-beam and four-column design, which consists of upper beam, slider (slide beam), working table and four columns.
Multi-functional Process Adaptation
Metal processing: thin plate stretching, deep drawing, bending, punching, calibrating, etc., applicable to the production of automotive cover parts, engine block, transmission shaft and other parts.
Non-metal molding: powder metallurgy, composite material molding, rubber product pressing, etc., to meet the needs of aerospace, rail transportation and other fields.
Special process: cattle and sheep licking brick briquettes, fish bait briquettes, hot forging molding, etc., reflecting the flexibility of the equipment.
Typical application cases
Automobile manufacturing: stretching curved parts such as inner door panels and engine hoods to ensure dimensional accuracy within ±0.1mm.
Aerospace: pressing large whole wall plate and skin, eliminating residual stress and enhancing structural strength.
Home appliance industry: production of stainless steel sinks, dishwashing sinks and other deep drawing products, reducing the welding process.
Compression molding process
Customer Case
Technical Specifications
| Parameter | Unit | YQ32-63 | YQ32-100A | YQ32-100B | YQ32-200A | YQ32-200B | YQ32-315A | YQ32-315B |
|---|---|---|---|---|---|---|---|---|
| Nominal Force | kN | 630 | 1000 | 1000 | 2000 | 2000 | 3150 | 3150 |
| Maximum System Working Pressure | MPa | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| Maximum Open Height of Slider | mm | 700 | 800 | 900 | 1100 | 900 | 1250 | 1000 |
| Maximum Stroke of Slider | mm | 400 | 500 | 600 | 500 | 600 | 800 | 600 |
| Effective Area of Workbench | mm | 610×500 | 630×550 | 750×700 | 1000×1000 | 800×800 | 1260×1160 | 800×800 |
| Slider Free Fall Speed | mm/s | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
| Pressing Speed | mm/s | 11-22 | 7-15 | 7-15 | 7-18 | 7-18 | 7-12 | 7-12 |
| Return Speed | mm/s | 80 | 90 | 90 | 90 | 90 | 100 | 90 |
| Ejecting Force | kN | 100 | 200 | 200 | 400 | 400 | 630 | 630 |
| Maximum Ejecting Stroke | mm | 160 | 200 | 200 | 200 | 200 | 300 | 300 |
| Name | Unit | YQ32-400 | YQ32-500 | YQ32-630 | YQ32-800 | YQ32-1000 | YQ32-1250 | YQ32-1600 |
|---|---|---|---|---|---|---|---|---|
| Nominal Force | kN | 4000 | 5000 | 6300 | 8000 | 10000 | 12500 | 16000 |
| Maximum System Working Pressure | MPa | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| Maximum Open Height of Slider | mm | 1250 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Maximum Stroke of Slider | mm | 800 | 900 | 900 | 900 | 900 | 900 | 900 |
| Effective Area of Workbench | mm | 1250×1160 | 1400×1400 | 1500×1500 | 1600×1600 | 1600×1600 | 1600×1600 | 1600×1600 |
| Slider Free Fall Speed | mm/s | 100 | 100 | 150 | 100 | 180 | 180 | 190 |
| Pressing Speed | mm/s | 5-11 | 10-18 | 9-18 | 7-18 | 10-18 | 6-15 | 6-14 |
| Return Speed | mm/s | 100 | 180 | 200 | 90 | 220 | 200 | 220 |
| Ejecting Force | kN | 630 | 1000 | 1000 | 400 | 1000 | 1000 | 1600 |
| Maximum Ejecting Stroke | mm | 300 | 300 | 300 | 200 | 300 | 300 | 300 |
